引用标准/Reference standares

IEC 61071 60068

工作温度范围Operating temperature range

-40~85℃

容量范围Capacitance

5.0~90μF

额定电压 Rated Voltage

500~1200VDC

容量偏差 Tolerance

±5%, ±10%

极间耐电压 Test voltage between terminals

1.5Ur(DC) 10s 25±5℃

极壳耐电压 Test voltage between terminals and case

3000V 50Hz 60S, 25±5℃

损耗角正切Dissipation factor

tgδ≤1×10-3 at 25±5℃ , 1KHz

绝缘电阻Insulation resistance

C*IR≥5000S, at 100VDC,25±5℃,60S

预期寿命Life expectancy

100000h at Un and 70℃
